Ceiling
PRODUCTS#FANWEI
Industrial factory, production
station, maintenance station, etc. Where requires
high brightness illumination.
PRODUCTS#TEDIAN
· Die-casting alloy shell with high pressure
electrostatic powder spray, high strength and corrosion resistance .
· Integrated design, external power, attracive appearance, convenient maintenance.
· High-quality LED chips, high luminous efficiency,
good color rendering, anti-impact and vibration resistance .
· Non-imaging secondary optical design，efficient using of light
energy，optional light distributions, wide, narrow, high racking.
· Constant current drive, wide
range input, intelligent protective circuit, stable
operation, ultra-long life .
· Excellent EMC design, no interferes
to electric power systems or other electrical equipment s.
· Variety installation types,
flexible optional.
PRODUCTS#JISHU
| 型號 Type | BY-80T |
| 功率 Power | 80W |
| 輸入電壓 Input Voltage | 100～240VAC 50~60Hz |
| 配光 Light Distribution | 寬光Wide Beam、窄光Narrow Beam |
| 系統輸出 System Output | 8800lm |
| 系統光效 System Luminous Efficiency | ≥110lm/W |
| 顯色指數 Color Rendering Index | ≥80 |
| 色溫 Color Temperature | 2700～6500K |
| 防護等級 Degree of Protection | IP42 |
| 環境溫度 Ambient Temperature | -40℃～55℃ |
| 重量 Weight | 2.9kg |
| 執行標準 Implementing Standard | GB7000.1 GB7000.201 GB17625.1 GB17743 |
PRODUCTS#XUAN
| 序號Serial number | 型號Type | 功率Power | 配光Light Distribution |
| 1 | BY-80T-WB | 80W | 寬光Wide Beam |
| 2 | BY-80T-NB | 80W | 窄光Narrow Beam |
PRODUCTS#TIHUAN
Can replace 150W metal halide lamps and other similar traditional
lamps with equivalent.
